EHS 109-LED-CLD

EHS 109-LED-CLD

  • $60.00

…is designed with low EMI and specially equipped with a customized proprietary Hybrid IC for higher reliability and greater efficiency in operation. Small and aesthetically in design. Easy installation. It stays inconspicuously and maintains the original interior decoration of the premises.
Suitable for Banks, Computer Rooms, Offices, Cinemas, Hotels, Shops, Supermarkets, etc..

Qty

Input Voltage : 230Vac 50/60Hz ± 10% or 115Vac 50/60Hz ± 10% or others
Battery : High temp rated Nickel Cadmium cells 2.4V 2.5Ah
Lamp Used : 1W SMT NICHIA White LED
Rated Period : > 3 hrs or others
Mode : Non-maintained
Operation Temperature : ta 40 °C
Power Consumption : < 1.4W
Charge Monitor : Super bright Green LED 5mm Ø
Recharge Period : 16 ~ 24 hrs
Emergency Luminance : 27 Im
Electromagnetic Field : 6.9m gause @ 0.1m
Charger : Hybrid controlled charger
Protection : Low volt cut-off to prevent battery over discharge. Incoming AC fuse, Circuit Protection Fuse and Battery DC fuse. Tropical climate protection coating on a hybrid control circuit
Construction : Electrode galvanized sheet steel with epoxy powder coating
Dimension : 112mm Ø x 170mm (H)
Packing : One unit per carton
Carton/Dimension : Double wall corrugated / 120mm(L) x 120mm(W) x 185mm(H)
Compliance : SS563-1:2010, SS563-2-2010/A1:2013, SSIEC60598-2-22-2016 SSIEC60598: PART 1:2016
Warranty : 1 Year

EHS-109-LED-CLD-1
